ASTM A213 Gr T5 Alloy Steel Seamless Tubes, Chrome Moly T5 Seamless Tubes, SA 199 T5 material, Alloy Steel T5 Welded Tubes supplier in India.
Alloy Steel Grade T5 Seamless EN 10216-2 Tubes, Alloy Steel T5 Ornamental Tubing, Astm A213/asme Sa213 Standard Tubing / T5 Alloy Grade Material Tubing Exporters in India
We are specialized in offering precision engineered ASTM A213 T5 Alloy Steel Seamless Tube, which is used in various engineering applications. These ASTM A213 / ASME SA213 T5 Alloy Steel SMLS Tubes are used in various application industries like Petroleum, chemical, power, gas, water, metallurgy, shipbuilding, construction, etc. These products are presented in different shapes and sizes, grades they are applicable both for engineering and industrial purpose. We are offered at competitive prices, these are developed using advanced technology. We are a reputed venture. We believe in providing top-notch quality of these Astm A213/asme Sa213 Standard Tubing / T5 Alloy Grade Material Tubing to our valuable clients..
Specification ASTM A213 T5 / ASME SA213 T5 Alloy Steel Tube :
| Size (Seamless) | 6.35mm o.d to 101.60mm o.d |
|---|---|
| Standards | ASTM A213, ASME SA213 |
| Equivalent Standards | EN 10216-2, ASTM A335, GOST 550-75, WN 1.7362, K41545 |
| Material | P5, K41545 |
| Equivalent Material | T5, 15Ch5M |
| Type | Seamless |
| Specialized in | Large Diameter Size |
| Outer Dimensions | 6-2500mm; WT:1-200mm |
| Wall Thickness | Schedule 3mm to 15mm. |
| Length | max 1~12m |
| Schedule | STD, SCH40, SCH80 |
| Form | Round, Square, Rectangular, Hydraulic Etc. |
| Length | Single Random, Double Random & Cut Length. |
| Tubing End | Plain End, Beveled End, Treaded. |
Chemical Compositions of ASTM A213 / ASME SA213 T5 Alloy Steel SMLS Tubes:
| C, % | Mn, % | P, % | S, % | Si, % | Cr, % | Mo, % |
|---|---|---|---|---|---|---|
| 0.15 max | 0.30-0.60 | 0.025 max | 0.025 max | 0.50 max | 4.00-6.00 | 0.45-0.65 |
Mechanical Properties ASTM A213 / ASME SA213 T5 Alloy Steel SMLS Tubes:
| Tensile Strength , MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|
| 415 min | 205 min | 30 min | 163 max |
Alloy Steel T5 Outside Diameter & Tolerance :
| Hot rolled | Outside Diameter, mm | Tolerance, mm |
|---|---|---|
| OD≤101.6 | +0.4/-0.8 | |
| 101.6＜OD≤190.5 | +0.4/-1.2 | |
| 190.5＜OD≤228.6 | +0.4/-1.6 | |
| Cold Drawn | Outside Diameter, mm | Tolerance, mm |
| OD＜25.4 | ±0.10 | |
| 25.4≤OD≤38.1 | ±0.15 | |
| 38.1＜OD＜50.8 | ±0.20 | |
| 50.8≤OD＜63.5 | ±0.25 | |
| 63.5≤OD＜76.2 | ±0.30 | |
| 76.2≤OD≤101.6 | ±0.38 | |
| 101.6＜OD≤190.5 | +0.38/-0.64 | |
| 190.5＜OD≤228.6 | +0.38/-1.14 |
Grade T5 Wall thickness & Tolerance :
| Hot rolled | Outside Diameter, mm | Tolerance, % |
|---|---|---|
| OD≤101.6, WT≤2.4 | +40/-0 | |
| OD≤101.6, 2.4＜WT≤3.8 | +35/-0 | |
| OD≤101.6, 3.8＜WT≤4.6 | +33/-0 | |
| OD≤101.6, WT>4.6 | +28/-0 | |
| OD>101.6, 2.4＜WT≤3.8 | +35/-0 | |
| OD>101.6, 3.8＜WT≤4.6 | +33/-0 | |
| OD>101.6, WT>4.6 | +28/-0 | |
| Cold Drawn | Outside Diameter, mm | Tolerance, % |
| OD≤38.1 | +20/-0 | |
| OD>38.1 | +22/-0 |
Length: 5800mm; 6000mm; 6096mm; 7315mm; 11800mm; 12000mm; and so on.
Max length: 16000mm, also U bending can be offered.
