ASTM A213 T2 alloy seamless pipes demonstrate a minimum tensile strength of 415 MPa and a
yield strength of 205 MPa. With a required minimum elongation of 30% and a maximum hardness limited to 163 HB,
these alloy pipes find extensive use in industries such as oil & gas, power, fertilizers, heat-exchangers,
paper & pulp, pharmaceuticals, chemicals, and water treatment.
The ASTM A213 Gr T2 Tube exhibits a minimum tensile strength of 415MPa and a minimum yield strength of 205MPa,
which are similar to the values of the 304 and 316 stainless steel grades. However, this carbon steel has a
higher hardness and toughness, with a maximum Brinell hardness of 163HB. The ASTM A213 specification ensures
its suitability for pressure vessel applications, while various standards such as ASME, ASTM, and API are
applicable. The Asme Sa213 T2 Tubing is commonly used in boilers, heat exchangers, superheaters, condensers,
and oil and gas line applications.
| Specifications | : | ASTM A 213 / ASME SA 213 |
| Dimensions | : | ASTM, ASME and API |
| Range | : | 1/2” OD up to 5” OD, customs diameters also available |
| Size | : | 6.35mm o.d to 101.60mm o.d |
| Schedule | : | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules, upto 12mm thk |
| Type | : | Seamless / Fabricated |
| Form | : | Round, Square, Rectangular, Hydraulic Etc. |
| Length | : | Single Random, Double Random & Cut Length. |
| Tubing End | : | Plain End, Beveled End, Treaded. |
| C, % | Mn, % | P, % | S, % | Si, % | Cr, % | Mo, % |
| 0.10-0.20 | 0.30-0.61 | 0.025 max | 0.025 max | 0.10-0.30 | 0.50-0.81 | 0.44-0.65 |
| Tensile Strength , MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
| 415 min | 205 min | 30 min | 163 max |
| Size Range | 1/8" –42” |
| Schedules | 20, 30, 40, Standard (STD), Extra Heavy (XH), 80, 100, 120, 140, 160, XXH & heavier |
| Standard | ASME SA213 |
| Grade | ASME SA213 T2 |
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Petrochemical Industries
Marine Industries
Food Processing Industries
Oil & Gas Industries
