Stainless Steel 904L Sheets, SS 904L Plates, Steel 904L Coils, Grade TP904L Stainless Steel Shim Sheets Exporters, SUS 904L SS chequer (floor) Plate, AISI Steel 904L Perforated Sheet Suppliers
Stainless Steel 904L Plates is one of the best Stainless Steel grades for corrosion resistance. This grade is written as 1.4539 or X1NiCrMoCu25-20-5 according to EN norm and it is written as UNS S08904 according to UNS norm. SS904L stainless grade contains very high levels of nickel, molybdenum, chromium, and combinations of all these elements making this stainless steel grade very resistant to corrosion resistance. SS 904L material is one of the strongest materials to corrosion.
Stainless Steel 904L Plates (DIN 1.4539) are fully austenitic, low-carbon stainless steel sheets enriched with molybdenum and copper. With high levels of nickel and chromium, SS Plates offer exceptional resistance to corrosion in both oxidizing and reducing environments. SS 904L Coils are specially designed for use in extreme corrosion conditions, making them ideal for the process industry. Grade 904L stainless steel plates also provide excellent resistance to warm seawater and chloride attacks. With its highly alloyed chemistry of 25% nickel and 4.5% molybdenum, SS 904L provides good chloride stress corrosion cracking resistance, pitting, and general corrosion resistance superior to Stainless Steel 316L and 317L molybdenum enhanced stainless steel.
The 904L plates and sheets fall under the astm b625 sheet specification. The material could be easily welded and could be fabricated. It can be cold-formed or hot-formed. The 904L stainless steel strip is used to produce pipes and other accessories. The 220MPa minimum yield strength and the 490MPa minimum tensile strength allow the ASME SB625 Shim to be very effective in shock absorption and connecting two parts.
ASTM B625 is a standard for chromium and nickel alloy products. 904L sheets can vary in use cases and types differ accordingly. The Alloy 904L Stainless Steel Shim is used to cover gaps between connections and is useful in pressing two components together without leakages. The best competitive stainless steel 904L price policy renders the best value for your money enabling you to access quality products at reasonable prices.
The Best Stainless Steel 904L Plate Supplier
Amardeep Steel is a leading supplier of Stainless Steel 904L Plates. The AISI 904l plates provide the mechanical, chemical, and testing properties for the 904L material-made Plates. The Stainless 904l Plate is used in similar applications only with thicker dimensions. We produce Stainless Steel 904L plates, and 904L sheets in different dimensions and we are capable of catering to any order. Please contact us for further inquiries.
Stainless Steel 904L Plates Specification
| Specification |
ASTM B 906/ASME SB 906, ASME Code Cases 1827 and N-253, SAE/AMS 5540, BS 3072NA14 and 3073NA14, DIN 17750, ISO 6208, EN 10095, MIL-DTL-23228. |
|---|---|
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard |
| standards and approvals |
|
| Plasma profiles | As per customer's drawings |
| Value added services | Laser cutting, Waterjet cutting, Plasma cutting, Bending and mechanical processing, edge preparation, welding, sawing and shearing. |
| VAS |
|
| Origin | Indian Origin, European Origin, Japanese Origin |
| Packing | Bundles with waterproof cloth outside or plywood box |
| Test | UT, SGS testing, TUV etc |
Stainless Steel 904l Plates Chemical Composition
| Element | % Present (in product form) |
|---|---|
| Carbon (C) | 0.02 |
| Silicon (Si) | 0.70 |
| Manganese (Mn) | 2.00 |
| Phosphorous (P) | 0.03 |
| Sulfur (S) | 0.01 |
| Chromium (Cr) | 19.00 - 21.00 |
| Nickel (Ni) | 24.00 - 26.00 |
| Nitrogen (N) | 0.15 |
| Molybdenum (Mo) | 4.00 - 5.00 |
| Copper (Cu) | 1.20 - 2.00 |
| Iron (Fe) | Balance |
Stainless Steel 904L Plates Mechanical Properties
| Product Form | ||||||||
|---|---|---|---|---|---|---|---|---|
| C | H | P | L | L | TW/TS | |||
| Thickness (mm) Max. | 8.0 | 13.5 | 75 | 160 | 2502) | 60 | ||
| Yield Strength | Rp0.2 N/mm2 | 2403) | 2203) | 2203) | 2304) | 2305) | 2306) | |
| Rp1.0 N/mm2 | 2703) | 2603) | 2603) | 2603) | 2603) | 2503) | ||
| Tensile Strength | Rm N/mm2 | 530 - 7303) | 530 - 7303) | 520 - 7203) | 530 - 7304) | 530 - 7305) | 520 - 7206) | |
| Elongation min. in % | Jmin (Longitudinal) | - | 100 | 100 | 100 | - | 120 | |
| Jmin (Transverse) | - | 60 | 60 | - | 60 | 90 | ||
Physical properties Of SS 904L Plates
Grade |
Density (kg/m3) |
Elastic Modulus (GPa) |
Mean Co-eff of Thermal Expansion (µm/m/°C) | Thermal Conductivity (W/m.K) |
Specific Heat 0-100°C (J/kg.K) |
Elec Resistivity (nΩ.m) |
|||
|---|---|---|---|---|---|---|---|---|---|
| 0-100°C | 0-315°C | 0-538°C | At 20°C | At 500°C | |||||
| 904L | 8000 | 200 | 15 | - | - | 13 | - | 500 | 850 |
SS 904L Plate Weight Chart
| Size (mm) | Weight per plate (Kg) |
Size(mm) | Weight per plate (Kg) |
|---|---|---|---|
| 4000 x 2000 x 2.0 | 136.0 | 3000 x 1500 x 5.0 | 191.0 |
| 4000 x 2000 x 3.0 | 204.0 | 4000 x 2000 x 5.0 | 340.0 |
| 2500 x 1250 x 4.0 | 106.0 | 2500 x 1250 x 6.0 | 159.0 |
| 3000 x 1500 x 4.0 | 153.0 | 3000 x 1500 x 6.0 | 230.0 |
| 4000 x 2000 x 4.0 | 272.0 | 4000 x 2000 x 6.0 | 408.0 |
| 2500 x 1250 x 5.0 | 133.0 |
Stainless Steel 904L Welding:
Grade 904L stainless steels also have excellent weldability which can be performed using all conventional methods. This steel does not require pre-heat and post-weld heat treatments.
Stainless Steel 904L Heat Resistance:
The steel structure collapses only at a temperature above 400 C. This grade of SS Plates gives the best oxidation resistance and has the structural stability which usually collapses at high temperatures like 400°C and above.
Other Available Products Of Stainless Steel 904L Plates:
• ASTM B625 Stainless Steel 904L Plates
• 904L Stainless Steel Plate
• Stainless Steel 904L Blank Plates
• Stainless Steel 904L Flat Plates
• ASTM A240M 904L PLATE
• ASTM A480 904L PLATE
• SUS 904L Shim Plates
• Stainless Steel 904L Chequered Plates
• SS ASME SB625 Steel 904L Plates
• ASTM B625 SS 904L Plates
• ASTM A240 TP904L PLATE
• ASTM A480M 904L PLATE
Application of Stainless Steel 904L Plate
- Wiring in electrostatic precipitators
- Oil refinery components
- Seawater cooling devices
- Gas scrubbing plants
- Pulp and paper processing industries
- Acetic, phosphoric, and sulphuric acid processing plants
