Amardeep steel centre is manufacturer, exporter & suppliers of premium quality ASTM A312 TP 410 Stainless Steel Pipes & tubes . We offer all our pipes & tubes in different sizes, grades, diameters and types like seamless, welded & fabricated. SS 410 pipes and tubes are used widely in critical industrial applications like construction, oil & gas, petrochemical, natural gas, general industrial applications, etc. These pipes & tubes are available in various sizes, shapes as per the requirements of our clients. These pipes & Tubes are offerd at very reasonable rates to our clients.
Specification :
| Standards | ASTM A240 / ASME SA240 |
|---|---|
| Size | 1/4" to 4" |
| Range | 5mm To 150mm |
| Thickness | 4.0mm - 100mm |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) |
Production according to national and international standards (e.g. ASME, ASTM, API, EN, DNV, etc.)
Chemical Composition :
| Grade | C | Mn | Si | P | S | Cr | MO | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 410 | Min | - | - | - | - | - | 11.5 | - | - | - |
| max | 0.15 | 1.00 | 1.00 | 0.040 | 0.030 | 13.5 | - | 0.75 | - |
Mechanical properties
| Tempering Temperature (0C) | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) | Elongation (% in 50mm) | Hardness Brinell (HB) | Impact Charpy V (J) |
|---|---|---|---|---|---|
| Annealed * | 480 min | 275 min | 16 min | - | - |
| 204 | 1310 | 1000 | 16 | 388 | 30 |
| 316 | 1240 | 960 | 14 | 325 | 36 |
| 427 | 1405 | 950 | 16 | 401 | # |
| 538 | 985 | 730 | 16 | 321 | # |
| 593 | 870 | 675 | 20 | 255 | 39 |
| 650 | 755 | 575 | 23 | 225 | 80 |
* Annealed properties are specified for Condition A of ASTM A276, for cold finished bar. |
|||||
Physical properties
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) |
Thermal Conductivity (W/m.K) |
Specific Heat 0-1000C (J/kg.K) |
Electrical Resistivity (n.m) | |||
|---|---|---|---|---|---|---|---|---|---|
| 0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
| 410 | 7750 | 200 | 9.9 | 11.4 | 11.6 | 24.9 | 28.7 | 460 | 570 |
Grade specifications
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
|---|---|---|---|---|---|---|---|
| BS | En | No | Name | ||||
| 410 | S41000 | 410S21 | 56A | 1.4006 | X12Cr13 | 2302 | SUS 410 |
| These comparisons are approximate only. The list is intended as a comparison of functionally similar materials not as a schedule of contractual equivalents. If exact equivalents are needed original specifications must be consulted. | |||||||
Types Of Stainless Steel 410 Plates, Sheets & Coils :
• Stainless Steel 410 Shim Sheets
• Stainless UNS S34709 Plates
• SS 410 Perforated Sheet Suppliers
• SS 410 Chequered Plate Dealer
• SS 410 Plain Sheets Stockholder
• Stainless UNS S34709 Circles
• Stainless Steel 410 Cold rolled sheet
• Stainless Steel DIN 1.4301 Rings
• Stainless Steel 410 Strips
• SS 410 Foils
• ASTM A240 Stainless Steel 410 Coils
• ss 410 Plates
