HB 450 Plate Supplier, HB 450, HB 450 Steel Plates Exporter, HB 450 Abrasion Resistant Steel Plates, HB 450 High Strength Steel Plates, HB 450 Wear Resistant Steel Plates Manufacturer in India.
Amardeep stands as a renowned exporter and supplier of Hardened 450 Plate. We specialize in providing Hardened 450 Steel Plate, offering a wide range of customizable options in terms of size, shape, and finishing to meet our clients' specific requirements. Feel free to reach out to us to inquire about the cost of Hardened 450 Plate.
Hardened 450 Wear Steel Plate is an abrasion-resistant steel plate boasting a nominal hardness of 450 HBW. It
combines excellent weldability and bendability, with the added option for guaranteed impact toughness, known as
Hardened® 450 Tuf. These Hardened 450 Sheets and Hardened 450 Plate Tuf variants are available in thicknesses
ranging from 3 to 130 mm, with Hardened 450 Plates available in widths up to 3350 mm and lengths up to 14,630
mm. For HB 450 Plate widths ≤ 1600 mm and thicknesses between 3 and 6 mm, the preferred widths are 1500 or 1600
mm. When dealing with Hardened 450 Plate thicknesses exceeding 80 mm, the preferred width is 1650 mm.
Hardened 450 Sheets find application in a wide array of components and structures prone to wear. Boasting an
additional 50 Brinell hardness over our Hardened 400 grade, Hardened 450 Plate offers improved abrasion and dent
resistance, resulting in extended wear life. These Hardened 450 Wear Resistant Steel Plates are characterized by
high strength and exceptional abrasion resistance.
Our product range also includes Welding Hardened 450 Plate, with a minimum Hardened 450 Plate Hardness of 450
HBW. This particular Hardened 450 Steel Plate excels in terms of high strength, resistance to contusions, and
longevity, capable of withstanding the test of time. Hardened 450 Wear Plate is predominantly used in
applications such as dump truck bodies, conveyors, hoppers and feeders, bulldozers, railroad cars, crushers, and
chutes.
We take immense pride in delivering high-quality Hardened 450 Sheets to a vast customer base. These sheets offer
superb cold bending and welding properties, ensuring they can withstand high impact while boasting a nominal
hardness of 450 HBW. Our HB 450 Plates are in high demand for their exceptional quality, reliability, and
durability across various usage environments. You can acquire top-grade Hardened 450 Plate from us at an
affordable price point.
Specification of HB 450 Plates
Width : 500-3000mm
Thickness : 3-130mm
Length : 1000-12000mm
Heat Treatment : N, Q+T
Surface Paint : EP, PE, HDP, SMP, PVDF
Hardened 450 Plates Chemical Composition
| C *) | Si *) | Mn *) | P | S | Cr *) | Ni *) | Mo *) | B *) |
|---|---|---|---|---|---|---|---|---|
| Max % | Max % | Max % | Max % | Max % | Max % | Max % | Max % | Max % |
| 0.26 | 0.7 | 1.6 | 0.025 | 0.01 | 1.40 | 1.50 | 0.6 | 0.005 |
HB 450 Plates Mechanical Properties
| Thickness | Hardness HBW | Typical yield strength MPa, |
|---|---|---|
| mm | min – max 1) | not guaranteed |
| 3 – 80 | 425 – 475 | 1100 – 1300 |
| (80) – 100 | 410 – 475 | 1050 – 1300 |
| (100) – 130 | 390 – 475 | 1000 – 1300 |
Hardened 450 Plates Equivalent Grades
| CHINA GRADE | CHINA STANDARD | EQUAL GRDAE | |
|---|---|---|---|
| JFE | SAB | ||
| NM450 | GB/T 24186-2009 | EH450 | HARDOX 450 |
Hardened 450 Plate Thickness, Hardened 450 Plate Hardness
| Thickness (mm) | Product | Hardness Range (HBW) |
|---|---|---|
| 2.5 – 6.4 | Cut Lengths | 360 – 420 |
| 5 – 15 | Heavy Plates | 360 – 420 |
| 15- 30 | Heavy Plates | 360 – 450 |
| 30 – 60 | Heavy Plates | 360 – 480 |
HB 450 Plate Sizes, Hardened 450 Plate Weight
| Thickness | Size | Lbs./Sq.Ft |
|---|---|---|
| 3/16" | 96" x 240" | 7.660 |
| 1/4" | 96" x 240" | 10.210 |
| 5/16" | 96" x 240" | 12.760 |
| 3/8" | 96" x 240" | 15.310 |
| 1/2" | 96" x 240" | 20.420 |
| 5/8" | 96" x 240" | 25.520 |
| 3/4" | 96" x 288" | 30.630 |
| 1" | 96" x 240" | 40.840 |
