SS UNS N08904 Pipes, Stainless Steel 904L Seamless Pipe, Stainless Steel N08904 Seamless Pipe, Stainless Steel 1.4539 Seamless Pipes Exporters, SS TP904L Welded Pipes Distributors, SS 904L Pipes Supplier, SS UNS N08904 Welded Pipes Manufacturer, SS 1.4539 Welded Pipe, Stainless Steel 904L Pipe, ASTM A312 Stainless Steel 904L Welded Pipe in Mumbai, India, 904L Stainless Steel Pipe.
Amardeep Steel is one of the 904L Stainless Steel Pipe Suppliers and we supply the pipes in different types and dimensions. The 904l material has 23% nickel, 19% chromium, carbon, manganese, silicon, phosphorus, sulfur, and 4% molybdenum in the composition with nitrogen in 0.1% as well. The 904L Stainless Steel Tube gets corrosion resistance and strength from the composition. 904l material has 220MPa yield strength and 490MPa tensile strength. The material also has a 70-90 Rockwell B hardness score. The Stainless Steel 904L Tubing belongs to ASTM B673 specification.
The dimensions of the tubes vary according to the ASTM, ASME, and API standards. 904L Pipes range from ½ inches to 16 inches in nominal bore size for seamless pipes, ½ to 24 inches for ERW pipes, and 6 to 100 inches for electric fusion welded pipes. The sizes range from 1/8 inch to 30 inches. These ASTM B677 UNS N08904 ERW Pipes are specialized as larger diameter pipes. There are varying schedules from sch20 through XXS. There are seamless, welded, fabricated, ERW and LSAW pipes. The 904L Stainless Steel Welded Pipes are good for welding. They can come in different pipe endings like plain, beveled, and treaded. Please contact us for more information on the products such as the UNS N08904 Seamless Pipe and the prices.
904L is the austenitic stainless steel material. The addition of molybdenum provides excellent resistance to localized attacks such as crevice corrosion and pitting by chlorides. Also, it has having very good resistance ability against reducing acids and the addition of copper gives it general corrosion resistance to various concentrations of sulphuric acid. The high alloying of the material gives it chloride stress corrosion cracking resistance but still, 904l material is susceptible 904L stainless steel pipes offer a yield strength of 220 MPa, tensile strength of 490 MPa, and hardness of 70-90, produced according to ASTM B673 specifications.
SS 904L pipe dimensions vary according to ASTM, ASME, and API standards. Seamless pipes range from ½ inch to 16 inches in nominal bore, ERW pipes range from ½ inch to 24 inches, and electric fusion welded pipes range from 6 to 100 inches. Overall, pipe sizes span from 1/8 inch to 30 inches. ASTM B677 UNS N08904 ERW pipes are available in various schedules, from SCH 20 to XXS, and come in seamless, welded, ERW, and LSAW forms.
904L stainless steel welded pipes are particularly well-suited for welding and are available with different end types such as plain, beveled, or threaded. As one of the leading 904L pipe suppliers and stainless steel 904L pipe manufacturers in India, Amardeep Steel ensures high-quality products for various industrial needs.
The 904L stainless steel price varies depending on several factors, including market demand and material thickness. This high-quality alloy is generally more expensive than standard stainless steel due to its excellent corrosion resistance and durability.
To Know More About the 904L Stainless Steel Pipe Price
SS 904L Material Specification
| Specifications | ASTM B673, B677 / ASME SB673, SB 677 |
|---|---|
| Dimensions | ASTM, ASME and API |
| SS 904L Pipes | 1/2″ NB – 16″ NB |
| ERW 904L Pipes | 1/2″ NB – 24″ NB |
| EFW 904L Pipes | 6″ NB – 100″ NB |
| Size | 1/8″NB TO 30″NB IN |
| Specialized in | Large Diameter Size |
| Schedule | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Type | Seamless / ERW / Welded / Fabricated / LSAW Pipes |
| Form | Round, Square, Rectangular, Hydraulic Etc |
| Length | Single Random, Double Random & Cut Length. |
| End | Plain End, Beveled End, Treaded |
SS 904L Chemical Composition
SS 904L pipes are high-alloy austenitic stainless steel, known for exceptional corrosion resistance. The chemical composition includes Chromium (19-23%), Nickel (23-28%), Molybdenum (4-5%), and Copper (1-2%). It also contains low carbon for improved weldability and structural integrity. This unique blend makes SS 904L ideal for aggressive environments.
| C | Cr | Cu | Mn | Mo | Ni | P | S |
|---|---|---|---|---|---|---|---|
| Max | Max | Max | Max | ||||
| 0.02 | 19.0-23.0 | 2.0 | 4.0-5.0 | 23.0-28.0 | 0.045 | 0.035 | 1.0 |
Stainless Steel 904L Pipe Mechanical Properties
|
Grade |
Tensile Strength (MPa) min |
Yield Strength 0.2% Proof (MPa) min |
Elongation (% in 50mm) min |
Hardness |
|
|---|---|---|---|---|---|
|
Rockwell B (HR B) |
Brinell (HB) |
||||
|
904L |
490 |
220 |
36 |
70-90 typical |
150 |
Stainless Steel UNS N08904 Pipe Equivalent Grades
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | KS |
|---|---|---|---|---|---|---|---|
| SS 904L | N08904 | 1.4539 | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 | SUS 904L | 904S13 | STS 317J5L |
Stainless Steel 904l Pipes Physical Properties
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
|---|---|---|---|---|---|---|---|---|---|
| 0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
| 904L | 8000 | 200 | 15.0 | – | – | 13.0 | – | 500 | 850 |
Tolerance Chart of 904L Stainless Steel Tube
| Stainless Steel 904L Pipe OD | astm b677 tp 904l Pipe Tolerance |
|---|---|
| 4 to 35 milimeter | +/- 0.08 milimeter |
| 35 to 38 milimeter | +/- 0.15 milimeter |
| 38 to 60 milimeter | +/- 0.20 milimeter |
| 60 and above | +/- 0.25 milimeter |
Size Chart of 904L Stainless Steel Tubes
| Wall Thickness | 904L Stainless Steel Pipe Sizes ( O.D.) |
|---|---|
| .010 | 1/16″ , 1/8″ , 3/16″ |
| .020 | 1/16″ , 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ |
| .012 | 1/8″ |
| .016 | 1/8″ , 3/16″ |
| .028 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 3/4″ , 1″ , 1 1/2″ , 2″ |
| .035 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 7/16″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .049 | 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/8″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .065 | 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 3/4″ , 2″ , 2 1/2″ , 3″ |
| .083 | 1/4″ , 3/8″ , 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 7/8″ , 2″ , 2 1/2″ ,3″ |
| .095 | 1/2″ , 5/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .109 | 1/2″ , 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .120 | 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 2 1/4″ , 2 1/2″ , 3″ |
| .125 | 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 3″ , 3 1/4″ |
| .134 | 1″ |
| .250 | 3″ |
| .375 | 3 1/2″ |
Stainless Steel 904L Pipe Schedule List
| 1/8″ IPS(.405″O. D.) | 3 1/2″ IPS( 4.000″O. D.) |
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4″ IPS(.540″O. D.) | 4″ IPS(4.500″O. D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8″ IPS(.675″O. D.) | 5″ IPS( 5.563″O. D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2″ IPS(.840″O. D.) | 6″ IPS(6.625″O. D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4″ IPS(1.050″O. D.) | 8 ” IPS(8.625″O. D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1″ IPS:(1.315′O. D.) | 10″ IPS(10.750″O. D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4″ IPS(1.660″O. D.) | 12″ IPS(12.750″O. D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2″ IPS(1.900″O. D.) | 14″ IPS(14.000″O. D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2″ IPS(2.375″O. D.) | 16″ IPS(16.000″O. D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2″ IPS(2.875″O. D.) | 18″ IPS (18.000″O. D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3″ IPS( 3.500″O. D.) | |
| SCH 5, 10, 40, 80, 160, XXH |
Manufacturing Standards of SS 904L Pipe
| ASTM | ASME | Description |
|---|---|---|
| ASTM A312 TP904L | SA 312 TP904L | Stainless Steel 904L Seamless and straight-seam welded austenitic pipe |
| ASTM A358 TP904L | SA 358 TP904L | ASTM A312 TP904L Electric fusion welded (EFW) austenitic pipe, up to 8 inch |
| ASTM A213 TP904L | SA 213 TP904L | Seamless and Welded Austenitic Stainless Steel Tubing |
| ASTM A249 TP904L | SA 249 TP904L | Welded Austenitic Steel Boiler, Superheater, Condenser and SS 904L Heat Exchanger, Tubes |
| ASTM A269 TP904L | SA 269 TP904L | Seamless and Welded Austenitic Stainless Steel 904L Tubing |
| ASTM A409 TP904L | SA 409 TP904L | 904L Welded Large Diameter Austenitic Steel Pipe |
| ASTM A376 TP904L | SA 376 TP904L | High Temperature SS 904L Seamless Austenitic Steel Pipe |
| ASTM A813 TP904L | SA 813 TP904L | Single-seam, single / double 904L welded austenitic pipe |
| ASTM A814 TP904L | SA 814 TP904L | Cold-worked welded 904L austenitic pipe |
| ASTM A554 TP904L | SA 554 TP904L | Stainless Steel 904L Welded Stainless Steel Mechanical Tubing and ASTM A312 TP904L Square Pipe |
| ASTM A511 TP904L | SA 511 TP904L | Stainless Steel 904L Seamless Mechanical Tubing |
| ASTM A632 TP904L | SA 632 TP904L | Small-Diameter Seamless and Welded Austenitic Stainless Steel 904L Tubing |
| ASTM A688 TP904L | SA 688 TP904L | Austenitic Stainless Steel 904L Feedwater Heater Tubes, Welded |
| ASTM A778 TP904L | SA 778 TP904L | Welded, Unannealed Austenitic Stainless Steel 904L Pipe/ Tube |
SS 904L Pipes & Tubes Application Industries
Our Stainless Steel 904L Pipes & Tubes are used in a wide range of applications and various industries. Below are a few of them:
- Petrochemical Industry
- Oil and Gas Industry
- Chemical Industry
- Power Plant Industry
- Energy Industry
- Pharmaceuticals Industry
- Pulp & Paper Industry
- Food Processing Industry
- Aerospace Industry
- Refining Industry
Stainless Steel 904L Pipe Exporter
Amardeep Steel is a trusted exporter of high-quality Stainless Steel 904L Pipe, supplying clients worldwide with products that meet diverse industrial needs.
Mexico, Afghanistan, Italy, Switzerland, Czech Republic, Algeria, Angola, Brazil, Poland, Colombia, Slovakia, Trinidad & Tobago, Tunisia, Chile, Bahrain, Iran, Indonesia, Libya, Croatia, Austria, Norway, Estonia, Belarus, Philippines, Mexico, China, Hungary, Iraq, Jordan, Bolivia, South Africa, Australia, Chile, Israel, Bhutan, Hong Kong, Germany, Poland, Kazakhstan, Spain, Macau, Pakistan, Sri Lanka, Lebanon, Namibia, Sweden, Qatar, Kuwait, Canada, Gambia, Greece, Ukraine, United Arab Emirates, Puerto Rico, Turkey, New Zealand, Oman, Netherlands, Venezuela, Finland, Argentina, United Kingdom, Yemen, Nigeria, Nigeria, Portugal, India, South Korea, Tibet, Malaysia, Peru, Russia, Denmark, Ghana, Singapore, Bulgaria, Iran, Morocco, Ecuador, Gabon, Costa Rica, Azerbaijan, United States, Taiwan, Belgium, Lithuania, Thailand, Bangladesh, Japan, Egypt, Saudi Arabia, Mongolia, Romania, France, Serbia, Ireland, Nepal, Vietnam, Kenya, Zimbabwe.
Stainless Steel 904L Tubes Exporter
Amardeep Steel is a prominent exporter of Stainless Steel 904L Tubes Exporter Exporter, delivering high-quality products to a diverse clientele across major cities in Europe and beyond.
Ukraine, Costa Rica, Macau, Bulgaria, Afghanistan, Ghana, Nigeria, New Zealand, Qatar, Taiwan, Morocco, Nepal, Malaysia, Portugal, Bolivia, Belgium, South Korea, Finland, Argentina, Azerbaijan, Kazakhstan, South Africa, Iran, Namibia, Chile, Bhutan, Israel, Yemen, Puerto Rico, Turkey, Croatia, Austria, Poland, Netherlands, Mongolia, Sweden, United Kingdom, Belarus, Germany, Colombia, Iraq, Gabon, Poland, Spain, United States, Ecuador, Philippines, Oman, Angola, Italy, Kenya, Lithuania, Lebanon, Gambia, Russia, Hong Kong, Ireland, Sri Lanka, Venezuela, Czech Republic, Romania, Greece, United Arab Emirates, Mexico, Bangladesh, Thailand, Australia, Estonia, Singapore, Indonesia, Mexico, Switzerland, Chile, Norway, Pakistan, Bahrain, Hungary, Slovakia, Egypt, China, Jordan, Serbia, Peru, Trinidad & Tobago, Tunisia, Kuwait, Zimbabwe, Algeria, Japan, Canada, France, India, Iran, Tibet, Libya, Nigeria, Vietnam, Saudi Arabia, Denmark, Brazil.
FAQs
What is the difference between 304 and 904L?
In the fashion industry, it is being used in watchmaking, as it is highly resistant to wear and tear. 904L is more resistant to general and localized corrosion than conventional chromium-nickel austenitic stainless steels such as SS 304 and SS 316L. 904L is highly resistant to chloride pitting and crevice corrosion.
What are the SS 904L properties?
904L stainless steel is known for its corrosion resistance, weldability, and toughness. It's resistant to pitting, crevice corrosion, and stress cracking. It's also resistant to a range of acids, including sulfuric, phosphoric, and acetic.
What is 904L stainless steel?
904L stainless steel is a high-end, non-magnetic, austenitic stainless steel with a low carbon content. It contains nickel, copper, molybdenum, and chromium.
