Inconel 600 Coiled Tube, ASTM B163 Inconel 600 Seamless Coiled Tubing Manufacturer, Inconel UNS N06600 Tubing, Stockist of Inconel 600 ERW Coiled Tube, Inconel Alloy 600 Coiled Tube Price in India.
600 Inconel Welded Coiled Tube, Supplier of High-Quality Inconel UNS N06600 Coiled Tubes, Inconel WERKSTOFF NR. 2.4816 Coiled Tube, Inconel 600 Alloy Polish Coil Tubing Exporter in Mumbai, India.
Nickel-based Inconel 600 Coiled Tube is intended to be utilized at raised temperature settings. Like most nickel alloys the ASME SB163 600 Inconel Coiled Tube can withstand heat and has prevalent corrosion resistance properties. Truth be told, the corrosion resistance property of SB163 Inconel 600 Alloy Seamless Coiled Tubing has been acquired from both nickel and chromium.
Both these components consist of the essential alloying substance of ASTM B163 N06600 Inconel Alloy 600 Coiled Tubing. This nickel chromium iron based ASTM B516 Inconel 600 Coiled Tube is meant to be used in the form of boiler, heat exchanger, and condenser tubes for applications which require general corrosion resistance as well as low temperature or high temperature services. Amardeep Steel Centre is the most trusted Inconel 600 Coied Tube Manufacturer & Supplier in India. These Inconel 600 Coiled Tubing are Manufactured as per the International Standard Guidelines under the supervision of Techincal Exprter.
ASTM B516 Inconel 600 Seamless Coiled Tubing:
| Size | 1/2" OD - 12" OD |
|---|---|
| OD | 3.00 - 219.10 mm |
| Thickness | 0.40 - 12.70 mm |
| Length | Single Random, Double Random & Cut Length. |
UNS N06600 Inconel 600 Welded Coiled Tubing:
| Size | 1/2" - 12" OD, Guage: 25 SWG - 10 SWG |
|---|---|
| OD | 6.35 to 114.3 mm O.D |
| Thickness | 0.8 - 12.7 mm |
| Length | up to 26 Meters |
Inconel UNS N06625 Coiled Tubing Mechanical Properties:
Alloy |
Density |
Melting Range |
Tensile Stress |
Yield Stress (0.2%Offset) |
Elongation |
|---|---|---|---|---|---|
Inconel 600 |
8.47 g/cm3 |
1413 °C (2580 °F) |
Psi - 95,000 , MPa - 655 |
Psi - 45,000 , MPa - 310 |
40 % |
Inconel UNS N06600 Coil Tube Chemical Composition:
Alloy |
C |
Mn |
Si |
S |
Cu |
Fe |
Ni |
Cr |
|---|---|---|---|---|---|---|---|---|
Inconel 600 |
0.15 max |
1.00 max |
0.50 max |
0.015max |
0.50 max |
6.00 - 10.00 |
72.00 min |
14.00 - 17.00 |
ASTM B163 Inconel 600 Seamless Coiled Tube Equivalent:
GRADE |
WERKSTOFF NR. |
UNS |
JIS |
BS |
GOST |
AFNOR |
EN |
|---|---|---|---|---|---|---|---|
Inconel 600 |
2.4816 |
N06600 |
NCF 600 |
NA 13 |
МНЖМц 28-2,5-1,5 |
NC15FE11M |
NiCr15Fe |
