ASTM A519 specification covers numerous grades of carbon and alloy steel mechanical tubing,
both hot-finished or cold-finished.
The steel used withinside the mechanical tubing may be forged in ingots or perhaps strand forged. When
metallic of various grades is sequentially strand forged, identity of the consequent transition fabric is
required. The seamless tubing is a tubular product made without a welded seam. It is typically synthetic
through warm running metallic, and if necessary, through in the end cold finishing the hot-worked tubular
product to supply the favored shape, dimensions and properties. Our ASTM A519/ ASME SA519 Carbon Steel Pipe
are Tubes undergoes hardness test, flattening test, flaring test, flange test, and hydrostatic test before
exporting them to our clients.
The tubes will be provided in the following shapes: round, square, rectangular and unique sections. Heat
evaluation will be made to decide the chances of the factors targeted. If secondary melting methods are used,
the warmth evaluation will be acquired from one re-melted ingot or the made of one re-melted ingot of every
number one melt. The tubing will be lined with a movie of oil earlier than shaping to retard rust while
targeted This summary is a quick precis of the referenced standard. It is informationally simplest and now no
longer a legitimate part of the same old; the whole textual content of the same old itself ought to be cited
for its use and application. ASTM does now no longer provide any assurance specific or implied or make any
illustration that the contents of this summary are accurate, entire or as much as date. Amardeep Steel Centre
Manufacture & Supplier these ASTM A519 Carbon Steel Tubes in India. We are also amongst the leading exporters
of these ASTM A519 Carbon Steel Seamless Tubes in the United States, Egypt, Kenya, United Kingdom, UAE, Dubai,
Saudi Arabia, Iran, Turkey, Korea.
Specification of ASTM A519 Carbon Steel Tubes |
||
Application | : | Drinking Water, Utilities Water, Chemical Handling, Gas Handling, Food Products |
Single Piece Length | : | 3 meter, 6 meter, 18 meter, 36 meter, >36 meter |
Size | : | 1/2 inch, 3/4 inch, 1 inch, 2 inch, 3 inch |
Unit Pipe Length | : | 3 meter, 6 meter, 9 meter, 18 meter, Customized |
Size / Diameter | : | 1/2 inch, 1 inch, 2 inch, 3 inch, 4 inch, >4 inch |
A519 Cd Seamless Tube Standard | : | ASTM A519 GR. 4130, ASTM A519 Grade 4130 (with IBR Test Certificate) |
Sch. & Swg. | : | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
ASTM A519 Tubing Thickness | : | 3-12mm |
A519 Mechanical Tubing Origin | : | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
ASTM A519 Tubing Tolerance | : | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
Craft | : | Cold rolled and Cold drawn |
ASTM A519 Tubing Type | : | Seamless / ERW / Welded / Fabricated |
Form of | : | Round, Square, Rectangular, Hydraulic Etc. |
ASTM A519 Tubing Length | : | Standard Double & In Cut length also. |
Tubing End | : | Plain End, Beveled End, Treaded |
Grade | C | Mn | P≤ | S≤ | Si | Cr | Mo |
1008 | ≤0.10 | 0.30-0.50 | 0.040 | 0.050 | - | - | - |
1010 | 0.08-0.13 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
1018 | 0.15-0.20 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
1020 | 0.18-0.23 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
1025 | 0.22-0.28 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
1026 | 0.22-0.28 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
4130 | 0.28-0.33 | 0.40-0.60 | 0.040 | 0.040 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
4140 | 0.38-0.43 | 0.75-1.00 | 0.040 | 0.040 | 0.15-0.35 | 0.80-1.10 | 0.15-0.35 |
Grade Designation | Condition * | Ultimate Strength | Yield Strength | Elongation In 2in (%) | Rockwell Hardness B-Scale | ||
Ksi | Mpa | Ksi | Mpa | ||||
1020 | HR | 50 | 345 | 32 | 221 | 25 | 55 |
CW | 70 | 483 | 60 | 441 | 5 | 75 | |
SR | 65 | 448 | 50 | 345 | 10 | 72 | |
A | 48 | 331 | 28 | 193 | 30 | 50 | |
N | 55 | 379 | 34 | 234 | 22 | 60 |
