Amardeep Steel is a top supplier of Tantalum Foils. These shiny foils are ductile, malleable, and highly resistant to corrosion, especially from acids, thanks to a protective oxide layer. They also have a high melting point and are resistant to oxidation. We offer these foils in various sizes and thicknesses to meet our customers' needs. Our Tantalum foils are widely used in industries such as laboratories, chemical processing, nuclear reactors, and even in missile parts.
Tantalum foil, available in over 359 variations, offers a wide range of thicknesses, widths, and lengths to meet diverse application needs. This material is renowned for its high melting point, excellent corrosion resistance, and good ductility.
It is commonly used in electronics to make capacitors and high-temperature heating elements. Additionally, it is utilized to produce chemical process equipment, such as heat exchangers and corrosion-resistant piping. The combination of these properties, along with its availability in various dimensions, makes tantalum foil a versatile choice for applications requiring high heat and chemical resistance.
Tantalum is also used in the production of super-alloys. Our products are known for their high quality and reliability, as they undergo strict quality control measures to ensure optimal performance. We are committed to providing excellent after-sales service and on-time delivery, which helps us build strong relationships with our clients.
Discover our premium tantalum products, including pipes, tubes, flanges, and fittings, known for their exceptional durability and corrosion resistance.
Tantalum Foil Product Details
Product | Purity | Thickness (mm) | Width (mm) | Length (mm) |
---|---|---|---|---|
Tantalum Foil | 99.95% min or 99.99% min | 0.03 - 0.07 | 30 - 200 | > 50 |
Tantalum Sheet | 99.95% min or 99.99% min | 0.07 - 0.5 | 30 - 700 | 30 - 2000 |
Tantalum Board | 99.95% min or 99.99% min | 0.5 - 10 | 50 - 1000 | 50 - 3000 |
Tantalum Foil Specification
Product Name | Thickness (mm) | Width (mm) | Length (mm) | Material | Standard | Purity |
---|---|---|---|---|---|---|
Tantalum Foil | 0.03-0.07 | 30-200 | >50 | UNS R05200, UNS R05400 | ASTM B708-98 | ≥99.9% or 99.95% |
Tantalum Strip | 0.03 | 1-1.5 | Up to 50000 | UNS R05200, UNS R05400 | ASTM B708-98 | ≥99.9% or 99.95% |
Chemical Composition of Tantalum Foil
Element | R05200 (%,Max) | R05400 (%,Max) |
---|---|---|
C | 0.01 | 0.01 |
O | 0.015 | 0.03 |
N | 0.01 | 0.01 |
H | 0.0015 | 0.0015 |
Fe | 0.01 | 0.01 |
Mo | 0.02 | 0.02 |
Nb | 0.1 | 0.1 |
Ni | 0.01 | 0.01 |
Si | 0.005 | 0.005 |
Ti | 0.01 | 0.01 |
W | 0.05 | 0.05 |
Tantalum Foil Mechanical Properties (Annealed Condition)
Grade and size | Annealed | ||
---|---|---|---|
Tensile strength min, psi (MPa) | Yield strength min,psi (MPa)(2%) | Elongation min, % (1 inch gage length) | |
Sheet, foil. and board (RO5200, RO5400) Thickness<0.060"(1.524mm) Thickness≥0.060"(1.524mm) | 30000 (207) | 20000 (138) | 20 |
25000 (172) | 15000 (103) | 30 | |
Ta-10W (RO5255) Sheet, foil. and board | 70000 (482) | 60000 (414) | 15 |
70000 (482) | 55000 (379) | 20 | |
Ta-2.5W(RO5252) Thickness<0.125" (3.175mm) Thickness≥0.125" (3.175mm) | 40000 (276) | 30000 (207) | 20 |
40000 (276) | 22000 (152) | 25 | |
Ta-40Nb (RO5240) Thickness<0.060"(1.524mm) | 40000 (276) | 20000 (138) | 25 |
Thickness>0.060"(1.524mm) | 35000 (241) | 15000 (103) | 25 |
Tantalum Niobium Alloy Application
- Electronics: Capacitors and components.
- Energy Storage: Batteries and storage systems.
- Medical Devices: Surgical implants and equipment.
- Metals & Alloys: Enhances metal properties.
- Nuclear Energy: Reactor components.
- Research: Scientific experiments and labs.
