SPFH590 Material Properties, SPFH590 Chemical Composition, SPFH590 Steel Equivalent, SPFH590 Mechanical Properties, jis g3134 SPFH590 Material Specification, jis g3134 steel, jis g3131 equivalent material. Amardeep Steel is SPFH590 jis g3134 steel tube supplier & exporter.
What are SPHC Steels?
SPHC steel is a hot-rolled steel that can be used in business. The JIS G 3131 standard defines SPHC
as a material grade and designation. JIS G 3131 is a standard for hot-rolled steel made in Japan.
Commercial quality hot rolled steel is a kind of steel that can be used for forming tasks, including
the sharing of a metallic sheet.
SM570 Steel is also made from hot-rolled steel, but because it is so strong, it is only used for welding. SPFH590 steel is a structural hot-rolled steel that is commonly used in the automotive industry for various applications such as chassis and other structural components. It is a high-strength steel with excellent tensile strength, and it is known for its excellent formability and weldability.
SPFH590 is a type of low carbon steel that contains various alloying elements such as manganese, silicon, phosphorus, and sulfur, among others, to achieve its desired mechanical and chemical properties.
When hot-rolled high-strength steels are used, it is possible to make parts thinner without affecting how well they work. In return, the weight savings and the whole process, from getting the materials to using the final component, can save a lot of money. Wheel hubs and rims, frames, and other auto parts are common places where this material is used.
Availability :
- High Strength Low Alloy Steels (HSLA) with minimum yield strength ranging from 35 ksi to 100 ksi, in 5ksi increments (ASTM A 1011, ASTM A 1018, SAE J1392, SAE J2340)
- Plate
- Sheet
- Coil
SPFH590 jis g3134 Material Specification :
| Product | Plat SPFH Hot-rolled High-strength Automotive Steel Plate |
| Kategori | Hot-rolled High-strength Automotive Steel Plate |
| Standard | JIS G3134 |
| Grades | SPFH540 & SPFH 590 |
| Country | Japan/Korea |
SPFH590 Steel Equivalent Grade
| Japan | US | Europe | Germany | France | England | Italy | Inter |
| JIS | SAE | EN | DIN,WNr | AFNOR | BS | UNI | ISO |
| SPFH 540 |
J2340 420XF | 10149-2 S420MC | |||||
| SPFH 590 | 490XF | S500MC | QSTE420TM | E420D | HR50F45 | Fe420TM | FeE420 |
SPFH590 jis g3134 Chemical Composition
| Grade | C | Si | Mn | P | S | Alt |
| SPFH540 | ≤0.15 | ≤0.50 | ≤1.80 | ≤0.025 | ≤0.025 | ≥0.010 |
| SPFH590 | ≤0.18 | ≤0.60 | ≤2.00 | ≤0.030 | ≤0.025 | ≥0.010 |
JIS g3134 SPFH590 Mechanical Properties
| Grade | Tensile Test | 180°Bending Test b Diameter | ||||||
| Yield strength (MPa) |
Tensile strength (MPa) |
Elongation L0=50mm，b=25mm(%) |
||||||
| Thickness (mm) | Thickness (mm) | |||||||
| 1.6~<2.0 | 2.0~<2.5 | 2.5~<3.25 | 3.25~6.0 | <3.25 | ≥3.25 | |||
| SPFH540 | ≥355 | ≥540 | ≥21 | ≥22 | ≥23 | ≥24 | 2a | 3a |
| SPFH590 | ≥420 | ≥590 | ≥19 | ≥20 | ≥21 | ≥22 | 3a | 3a |
SPFH590 Tensile Strength
| Grade SPFH | 490 | 540 | 590 | 590DP | 780 | 780DP |
| Min. Tensile Strength |
71.1 ksi | 78.3 ksi | 85.6 ksi | 85.6 ksi | 113.1 ksi | 113.1 ksi |
SPFH590 Tensile Strength
| Grade SPFH | 490 | 540 | 590 | 590DP | 780 | 780DP |
| Min. Tensile Strength |
71.1 ksi | 78.3 ksi | 85.6 ksi | 85.6 ksi | 113.1 ksi | 113.1 ksi |
SPFH590 jis g3134 Applications
- Automobile frame,
- wheel discs and rims,
- frames,
- hood,
- roof,
- fender,
- front end carrier,
- sub frame,
- rear floor,
- side outer,etc
