Titanium Grade 2 Plates, Sheets, and Coils are made from Titanium Grade 2, a commercially pure titanium alloy known for its excellent balance of strength, corrosion resistance, and formability. Titanium Grade 2 Plates are flat, thick sections used in structural applications requiring both durability and strength, and are commonly found in aerospace, marine, and chemical processing industries.
Titanium Sheets are thinner and more versatile, used where lightweight and corrosion-resistant materials are needed, making them ideal for components that require flexibility and ease of fabrication.
Titanium Coils are continuous rolls of Titanium Grade 2 sheet material, which are useful in manufacturing processes requiring long, uninterrupted strips that can be cut or shaped as needed. Titanium Alloy Grade 2 is prized for its superior corrosion resistance, especially in harsh environments like seawater or chemical processing, and it offers good weldability and formability for a wide range of demanding applications.
Titanium Gr 2 Plates Sheets Coil Supplier
Amardeep Steel is a leading supplier of Titanium Grade 2 Sheet is composed of commercially pure titanium with trace amounts of nitrogen, carbon, oxygen, iron, hydrogen, and other elements. This material is utilized in a variety of applications, including airframe skins, ductwork, brackets, galley equipment, chemical processing plants, cryogenic vessels, and heat exchangers.
Titanium gr 2 material has a melting point of 1660 degrees Celsius, which makes it suitable for high-temperature applications. Titanium Grade 2 Coils are commonly used in heat exchangers, boilers, and condenser components.
Additionally, the Titanium sheets can be supplied in various forms such as foils, coils, strips, and other customized shapes. The material is non-magnetic and possesses high strength, further enhancing its suitability for demanding applications. For more information on titanium sheet price, please contact us.
Titanium Gr 2 Plates Specification
| Specifications | ASTM B265/ ASME SB265 |
| Size | 1000 x 2000 milimeter, 1220 x 2440 milimeter, 1500 x 3000 milimeter, 2000 x 2000 milimeter, 2000 x 4000 milimeter |
| tdickness | 0.1 to 12 milimeter |
| Form | Plates, Sheet, Slatting Coils, Coils, Foils, Plain Sheet, Shim Sheet, Strip, Rolls, Perforated Coils, Flats, Blank , Ring |
| Finish | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met witd Plastic Coated) |
| Hardness | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
Titanium Gr 2 Chemical Composition
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade 2 Plate | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
Titanium Gr 2 Coil Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 Plate | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
Titanium Gr 2 Plates Sheets Coil Equivalent Grade
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 2 Plate | 3.7035 | R50400 |
ASTM B348 Grade 2 Titanium Plate Dimensions
| Titanium gr2 Plate Surface finish Chart | Gauge (inch) | Width (max inch) |
| 2B – Cold rolled, pickled, heat treated, skin passed Plate | 10–24 | 72* |
| 2D – Cold rolled, pickled plate, heat treated | 12–24 | 60 |
| BA Mexinox only | 18–28 | 48 |
| Polished plate/ sheet (not brushed) | 11–24 | 60 |
| Temper hot rolled plate Mexinox only | 13–29 | 48 |
ASTM B348 grade 2 titanium Plate Metric Dimensions
| Titanium Sheet Surface finish Chart | Gauge (inch) | Width (max inch) |
| 2B – Cold rolled, pickled, heat treated, skin passed Sheet | 10–24 | 72* |
| 2D – Cold rolled, pickled plate, heat treated | 12–24 | 60 |
| BA Mexinox only | 18–28 | 48 |
| Polished plate/ sheet (not brushed) | 11–24 | 60 |
| Temper hot rolled plate Mexinox only | 13–29 | 48 |
Density of Titanium Gr 2 Coil
| UNS R50400 Titanium Grade 2 Plate density |
| 0.1630 lb/in³ 4.512 g/cm3 |
Grade 2 Ti Cold Rolled Plates Thickness
| 0.5 mm 0.6 mm 0.8 mm 1.0 mm 1.2 mm 1.5 mm 1.6 mm 1.8 mm 2.0 mm 3.0 mm |
4.0 mm |
Melting Point of Titanium ASTM B265 Grade 2 Strip
| ASTM B265 Titanium Alloy Gr 2 Plate melting range |
| °F: 3020-3040 °C: 1660-1671 |
Titanium Gr 1 Sheets and Plates Applications
- Petrochemical
- Oil & Gas
- Chemical
- Power Plants
- Energy
- Pharmaceuticals
- Pulp & Paper
- Food Processing
- Aerospace
- Refining
