What are Copper Nickel Pipes and Tubes?
Copper Nickel Pipes are wrought alloys with a mixture of copper and nickel. It has excellent corrosion resistance and superior strength and machinability. Copper Nickel Pipes are particularly well suited for marine applications. The corrosion resistance of copper-nickel pipes is remarkably high, and they are also very suitable for cryogenic applications.
Copper Nickel Tube products are available in various types and specifications. Copper-nickel 90/10 Pipes and Tubes and Copper-nickel 70/10 pipes and tubes are available in seamless and welded construction. Typical applications include seawater tube work, heat exchangers, and hydraulic lines. Copper Nickel products are also used in marine and offshore oil and gas applications. In addition to marine and industrial applications, they are also used for evaporators, heat exchangers, and chillers.
Copper Nickel Pipe Supplier
Amardeep Steel is a leading supplier of Copper Nickel Pipes and Tubes can be found in various pressure classes. Schedule 40 Copper Nickel Pipes and Alloy 20 Tubes are ideal for low-pressure applications, while Schedule 80 Copper Pipes are used for high-pressure applications. ASTM B111 specifies the testing methods for cu-ni pipe and Tubes. The standard also specifies the diameter, wall thickness, and length of copper nickel pipes.
As a leading Copper Nickel Pipe supplier, We are committed to providing high-quality products and using only the best raw materials. This ensures that our products are durable and long-lasting. Cu-Ni Pipes is a copper-nickel alloy that exhibits superior corrosion resistance and is commonly used in marine hardware and piping systems. This alloy is also used in propellers and crankshafts.
What are Copper Nickel Pipes?
Copper Nickel Pipes are pipes made of copper nickel alloy that have excellent corrosion resistance properties making them suitable for use in marine and coastal environments. Copper Nickel Alloy exhibits superior corrosion resistance and is commonly used in marine hardware and piping systems.
What are the Uses of Copper Nickel tubes?
Cupro Nickel Tubes are commonly used in marine & offshore applications, water treatment plants, desalination plants, chemical processing plants, and Power Generation Copper-nickel pipes and components can be used in steam turbine condensers, oil coolers, auxiliary cooling systems, and high-pressure pre-heaters at nuclear and fossil fuel power plants.
Cupro Nickel Tubes have excellent corrosion resistance properties, high strength & durability, and are suitable for use in high-temperature and high-pressure environments. The high quality of alloy utilization has led it to offer excellent qualities including high tensile strength, reusable, and excellent formability. Also, it is highly resistant to mechanical stresses, greater resistance to high temperature, and high resistance to high pressure.
Explore our extensive selection of Copper Nickel products, such as pipes, tubes, flanges, and fittings, all recognized for their excellent corrosion resistance.
Copper Nickel Pipe Specifications
| Specifications | Details |
|---|---|
| Specifications | ASTM / ASME SB 111 / 151 / 466 |
| Standard | ASTM, ASME and API |
| Size | 1/2" TO 6' IN OD & NB IN Various SWG & SCH |
| Outer Diameter | 4.00 to 22.00 mm |
| Wall Thickness | Between 0.15mm and 1.50 mm |
| Length | Single Random, Double Random & Required Length |
| Schedule | SCH20, SCH30, STD, SCH80, XS, SCH60, SCH120, SCH140, SCH160, XXS |
| Types | Seamless, ERW, Welded, EFW, Fabricated, CDW |
| Form | Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes |
| End | Plain End, Beveled End, Threaded |
| Grades | Copper Nickel 90/10 (C70600), Cupro Nickel 70/30 (C71500), UNS C71640 |
C70600 Chemical Composition
Copper nickel pipe is typically made of a cupronickel alloy, which is a combination of copper and nickel, along with small amounts of other elements:
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
|---|---|---|---|---|---|---|
| Cu-Ni 90-10 | 88.6 min | 1.0 max | .05 max | 9-11 max | 1.8 max | 1 max |
| Cu-Ni 70-30 | 65.0 min | 1 max | .05 max | 29-33 | 0.4-1.0 | 1 max |
Mechanical Properties of Cu-Ni Pipes
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Copper Nickel 90-10 / 70-30 | 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 90-1000 psi | 30 % |
Copper Nickel Pipe & Tube Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Copper Nickel 90/10 | 2.0872 | C70600 |
| Copper Nickel 70/30 | 2.0882 | C71500 |
Cupro Nickel Tubes Physical Properties
| Property |
Metric Units
|
Imperial Units
|
|---|---|---|
|
Melting Point (Liquidus)
|
11,500°C
|
21,000°F
|
|
Melting Point (Solidus)
|
11,000°C
|
20,100°F
|
|
Density
|
8.94 gm/cm³ @ 20°C
|
0.323 lb/in³ @ 68°F
|
|
Specific Gravity
|
8.94
|
8.94
|
|
Coefficient of Thermal Expansion
|
17.1 x 10 -6 / °C (20-300°C)
|
9.5 x 10 -5 / °F (68-392°F)
|
|
Themal Conductivity
|
40 W/m. °K @ 20°C
|
23 BTU/ft³/ft/hr/°F @ 68°F
|
|
Thermal Capacity (Specific Heat)
|
380 J/kg. °K @ 20°C
|
0.09 BTU/lb/°F @ 68°F
|
|
Electrical Conductivity (Annealed)
|
5.26 microhm?¹.cm?¹ @ 20°C
|
9.1% IACS
|
|
Electrical Resistivity (Annealed)
|
0.190 microhm.cm @ 20°C
|
130 ohms (circ mil/ft) @ 68°F
|
|
Modulus of Elasticity (tension)
|
140 GPa @ 20°C
|
20 x 10 6 psi @ 68°F
|
|
Modulus of Rigidity (torsion)
|
52 GPa @ 20°C
|
7.5 x 10 6 psi @ 68°F
|
Cupro Nickel Pipe Dimension Tolerance
| Material | Ultimate Tensile Strength1000 psi (MPa) | Yield Strength 0.5% Ext.under Load 1000 psi (MPa) | YElongation % in 2 in. | Fatigue Strength (10x7 cycles) 1000 psi (MPa) | Burst Pressure* 1000 psi (MPa) |
|---|---|---|---|---|---|
| Copper-brazed Steel | 48-55 (0.330-0.380) | 28-34 (0.190-0.235) | 30-40 | 30 (0.210) |
19.5 (0.135) |
| C12200-Phosphorus deoxidized Copper | 32-38 (0.220-0.265) | 10-14 (0.070-0.100) | 45-60 | 10 (0.070) |
12 ( 0.083) |
| C70600-Copper Nickel 90-10 | 48-54 (0.330-0.370) | 16-22 (0.110-0.150) | 40-55 | 15 (0.100) |
19 (0.130) |
Copper Nickel Pipes & Tubes Available Types
| Copper Nickel 90-10 Pipes | Copper Nickel 70-30 Tubes |
| Copper Nickel UNS C70600 Seamless Pipes | Copper Nickel 70-30 ASTM B151 Seamless Tube |
| 90-10 Copper Nickel Welded Pipes | 70-30 Alloy Seamless Tubing |
| 90-10 Copper Nickel Seamless Pipe Suppliers | ASTM B466 Copper Nickel 70-30 Welded Pipe |
| Copper Nickel UNS C71500 ERW Pipes Dealer | Copper Nickel 70-30 Tubing Exporter |
| 90-10 Cu-Ni B466 Welded Tubes Stockholder | Copper Nickel 70-30 Seamless Tube Distributors |
| 70-30 Copper Nickel Square Tubing | Copper Nickel DIN 2.0872 Pipes Manufacturer |
| ASME SB111 Cu-Ni 90-10 Seamless Pipe | ASTM B466 90-10 Copper Nickel Welded Tube |
| ASTM B151 Copper Nickel 70-30 Welded Pipe | ASME SB730 90-10 Alloy Welded Tube |
| Copper Nickel DIN 2.0882 EFW Pipe | 90-10 Copper Nickel Tubes Stockist |
| 70-30 Copper Nickel Rectangular Pipes | Copper Nickel 90-10 EFW Tube |
| 90-10 Copper Nickel Heat Ex-changer Tubing | 70-30 Copper Nickel Seamless Pipe |
Copper Nickel Pipes & Tubes Application
90-10 / 70-30 Copper Nickel Pipes & Tubes are known to deliver exceptional performance and are generally developed to meet the demands. We offer a broad range of 90-10 / 70-30 Copper Nickel Seamless Pipe & Tube through a worldwide network of stock-keeping branches. These 90-10 / 70-30 Nickel Pipes & Tubing is used in various industries like:
- Copper Nickel 90-10 Seamless Pipes Used in Oil and Gas Pipeline
- ASTM B111 Nickel 70-30 Seamless Tubing Uses in Chemical Industry
- Grade 90-10 Copper Nickel Welded Pipe used in Plumbing
- Nickel ASTM B151 70-30 Welded Tubes used in Heating
- ASTM B111 90-10 Nickel Seamless Pipe uses in Water Supply Systems
- ASTM B466 70-30 Copper Nickel Welded Pipe Used in Power Plant
- Alloy 90-10 ERW pipes used in the Paper & Pulp Industry
- 70-30 Nickel EFW Tubes used in General Purpose Applications
- ASME SB466 Alloy 90-10 Welded Pipe used in the Fabrication Industry
- Copper Nickel 70-30 Pipes used in the Food Processing Industry
- ANSI Nickel 90-10 Tubes used in Structural Pip
Copper Nickel Pipe Exporter
Amardeep Steel is a trusted exporter of high-quality Copper Nickel Pipe, supplying clients worldwide with products that meet diverse industrial needs.
Mexico, Afghanistan, Italy, Switzerland, Czech Republic, Algeria, Angola, Brazil, Poland, Colombia, Slovakia, Trinidad & Tobago, Tunisia, Chile, Bahrain, Iran, Indonesia, Libya, Croatia, Austria, Norway, Estonia, Belarus, Philippines, Mexico, China, Hungary, Iraq, Jordan, Bolivia, South Africa, Australia, Chile, Israel, Bhutan, Hong Kong, Germany, Poland, Kazakhstan, Spain, Macau, Pakistan, Sri Lanka, Lebanon, Namibia, Sweden, Qatar, Kuwait, Canada, Gambia, Greece, Ukraine, United Arab Emirates, Puerto Rico, Turkey, New Zealand, Oman, Netherlands, Venezuela, Finland, Argentina, United Kingdom, Yemen, Nigeria, Nigeria, Portugal, India, South Korea, Tibet, Malaysia, Peru, Russia, Denmark, Ghana, Singapore, Bulgaria, Iran, Morocco, Ecuador, Gabon, Costa Rica, Azerbaijan, United States, Taiwan, Belgium, Lithuania, Thailand, Bangladesh, Japan, Egypt, Saudi Arabia, Mongolia, Romania, France, Serbia, Ireland, Nepal, Vietnam, Kenya, Zimbabwe.
Cu-Ni Pipes Exporter
Amardeep Steel is a prominent exporter of Cu-Ni Pipes, delivering high-quality products to a diverse clientele across major cities in Europe and beyond.
Ukraine, Costa Rica, Macau, Bulgaria, Afghanistan, Ghana, Nigeria, New Zealand, Qatar, Taiwan, Morocco, Nepal, Malaysia, Portugal, Bolivia, Belgium, South Korea, Finland, Argentina, Azerbaijan, Kazakhstan, South Africa, Iran, Namibia, Chile, Bhutan, Israel, Yemen, Puerto Rico, Turkey, Croatia, Austria, Poland, Netherlands, Mongolia, Sweden, United Kingdom, Belarus, Germany, Colombia, Iraq, Gabon, Poland, Spain, United States, Ecuador, Philippines, Oman, Angola, Italy, Kenya, Lithuania, Lebanon, Gambia, Russia, Hong Kong, Ireland, Sri Lanka, Venezuela, Czech Republic, Romania, Greece, United Arab Emirates, Mexico, Bangladesh, Thailand, Australia, Estonia, Singapore, Indonesia, Mexico, Switzerland, Chile, Norway, Pakistan, Bahrain, Hungary, Slovakia, Egypt, China, Jordan, Serbia, Peru, Trinidad & Tobago, Tunisia, Kuwait, Zimbabwe, Algeria, Japan, Canada, France, India, Iran, Tibet, Libya, Nigeria, Vietnam, Saudi Arabia, Denmark, Brazil.
FAQs
1. What is the composition of copper-nickel pipe?
While the basis of the alloy is 90% copper and 10% nickel, small amounts of iron and manganese are introduced during the alloying process to enhance performance. Copper Nickel 90/10 is an excellent choice for applications where erosion, stress-erosion, and biofouling in saltwater atmospheres are a consideration.
2. What is the ASTM for copper nickel pipe?
ASTM B466 Cupro Nickel 90/10 Pipe has great applications in Offshore & Marine, Saltwater pipes and fittings, hot water tanks, saltwater baffles, propeller sleeves, valve and pump components, flanges, boat hulls, marine fittings, and marine hardware.
3. What is the purity of copper pipes?
The copper in the water tube has a minimum purity of 99.9% copper (including minute amounts of silver), making it one of the purest of any of the common metals in commercial use.
