Amardeep, located in the vibrant city of Mumbai, India, has established an esteemed
reputation as a supplier, stockist, and exporter of Brinar 500 Plates. These plates are highly
regarded for their exceptional resistance to abrasion and boast superior qualities including
strength, toughness, excellent bendability, and weldability. They are the preferred choice for
applications in structures subjected to moderate wear and challenging conditions.
Within our extensive inventory, you'll find Brinar 500 Plates available in a broad range of
thicknesses, spanning from 4.0 to 130.0 mm, widths extending up to 3350 mm, and lengths of up to an
impressive 14630 mm. We are committed to meeting specific requirements, offering Brinar 500 Plates
with thicknesses ranging from 2.0 to 8.0 mm, widths up to 1650 mm, and lengths stretching to 16000
mm.
Brinar 500 Plates fall under the category of Abrasion Resistant (AR) steel, meticulously designed to
deliver robust performance in environments characterized by high levels of wear. They are also
recognized by alternative designations like Wear Resistant Steel 500 or ABREX 500 and are meticulously
crafted from top-tier, long-lasting steel. These plates are an exceptional choice for extending the
operational lifespan of machinery, components, and structures that endure the most demanding conditions.
The remarkable utility of Brinar 500 Steel Plates is evident in applications where steel is exposed to
significant abrasion or wear. Their impressive Brinell hardness (HB rating) makes them suitable for
scenarios that demand extraordinary wear and abrasion resistance. The use of abrasion-resistant steel
significantly enhances the durability of factories, equipment, and structures, thus elevating levels of
reliability, stability, and protection. Moreover, it contributes to the reduction of repair costs
associated with wear and breakdowns.
Typical applications for Brinar 500 Steel Plates encompass a wide array of industries, including
quarries, construction machinery, concrete aggregate molds, mining machinery, extractors, cement plants,
refractory product plants, and numerous other sectors.
At Amardeep, our paramount objective revolves around ensuring utmost customer satisfaction. Our team of
highly trained experts is unwaveringly dedicated to producing top-tier products. In our unwavering
pursuit of the highest standards, we subject our Brinar 500 Plates to a comprehensive battery of tests.
These encompass mill tests, raw material assessments, hardness evaluations, 100% radiography
examinations, micro-testing, intergranular corrosion inspections, chemical analyses, third-party
inspections, and positive material identification assessments. These rigorous quality checks provide an
unambiguous assurance that our Brinar 500 Plates are devoid of defects and are safe for deployment in
diverse climatic conditions.
| Item | Brinar 500 Plates |
| Grade | Wear Resistant Plates |
| Thickness | 5mm to 150mm |
| Width | 1,500mm to 2,500mm |
| Length | 6,000mm to 12,000mm |
| Heat Treatment | Rolling/Normalised, N, Q+T |
| Surface Paint | PVDF, PE, HDP, SMP, EP |
| Production Process | Hot rolled plate (HR) |
| PLATE | C | Si | Mn | P | S | Cr | Ni | Mo | B | CEV | CET |
| THICKNESS MM | MAX % | MAX % | MAX % | MAX % | MAX % | MAX % | MAX % | MAX % | MAX % | TYPV | TYPV |
| 4-13 | 0.27 | 0.7 | 1.6 | 0.025 | 0.01 | 1.0 | 0.25 | 0.25 | 0.004 | 0.49 | 0.34 |
| (13) -32 | 0.29 | 0.7 | 1.6 | 0.025 | 0.01 | 1.0 | 0.50 | 0.30 | 0.004 | 0.62 | 0.41 |
| (32) -40 | 0.29 | 0.7 | 1.6 | 0.025 | 0.01 | 1.0 | 1.00 | 0.60 | 0.004 | 0.64 | 0.43 |
| (40) -80 | 0.30 | 0.7 | 1.6 | 0.025 | 0.01 | 1.50 | 1.50 | 0.60 | 0.004 | 0.74 | 0.46 |
| Thickness | Hardness HBW | Typical yield strength MPa, |
| mm | min - max 1) | not guaranteed |
| 3 - 80 | 425 - 475 | 1100 - 1300 |
| (80) - 100 | 410 - 475 | 1050 - 1300 |
| (100) - 130 | 390 - 475 | 1000 - 1300 |
| Grade | Longitudinal test, typical impact energy, Charpy V 10 x 10 mm test specimen. |
| 500 BHN | 37J / -40*c |
