Grade S355 is a low-carbon manganese-containing steel alloy known for its medium tensile strength, excellent weldability, and good impact resistance. It performs well in sub-zero temperature applications. Under specification EN 10210, the designation includes symbols indicating impact properties. For example, "S355J2H" specifies that the steel has impact properties at 0°C and -20°C.
The letter "H" in S355J2H designates hollow-section products like the S355J2H Pipe, while the "S" indicates structural steel. The EN 10210 S355J2H Seamless Pipe is known for its excellent impact strength due to its composition and design. Manganese in the carbon steel enhances both strength and hardness. Additionally, hollow sections like the S355J2H Pipes have thicker walls compared to regular pipes, which contributes to their sturdiness and durability.
Amardeep Steel is a leading supplier of S355J2H EN 10210 Pipes. Our S355J2H pipes are used extensively in oil, gas, fluid exchange, boilers, heat exchangers, and petroleum and petrochemical industries. These products adhere to the BS EN 10210 standard and are available in wall thicknesses ranging from 0.5mm to 40mm. We produce pipes with lengths from 6000mm to 14000mm and sizes ranging from 10mm x 10mm to 800mm x 800mm.
S355J2H Pipe is a low carbon steel with a chemical composition including 0.22% carbon, 0.55% silicon, 1.6% manganese, and minimal phosphorus and sulfur. Known for its corrosion resistance and ability to withstand extreme temperatures, it features excellent dimensional accuracy and a superior finish. These pipes offer a tensile strength ranging from 510 MPa to 680 MPa and a minimum yield strength of 355 MPa. Although not as strong as higher carbon grades, S355J2H pipes provide considerable strength and stress resistance, making them suitable for oil, gas, and petroleum transportation, as well as in boilers, heat exchangers, and fluid systems.
| Size | Round Pipes – OD 13.7-1214mm Square Pipes – 10 X 10 mm – 800 X 800 mm Rectangular Pipes – 10mm x 20mm – 400 x 800mm |
|---|---|
| Wall Thickness | 1.0mm To 40mm |
| Length | 6 M, 12 M & Custom Size |
| Type | Round, Square, Rectangular Welded, Seamless, Fabricated, ERW |
| Surface Finish | Shot blasting, Oiled, Black Phosphating, Black, Paint, Mirror, Galvanized, Hairline, Anti Corrosive |
| Material grades | ASTM A500 – Gr.A, Gr.B, Gr.C, Gr.D SS330, SS400, STK490, C250, C350, C450 EN 10210/EN 10219 – S185, S235JR, S235J0, S355JR, S355J0, S355J2 20#, 45#, 16Mn, 304, 304L, 316, 316L |
| End Type | Plain, Screwed, Bevel, Threaded |
| Grade | C | Si | Mn | P | S |
|---|---|---|---|---|---|
| S355J2H (1.0576) | max 0.22 | max 0.55 | max 1.6 | max 0.03 | max 0.03 |
| Property | Specification |
|---|---|
| Tensile Strength (Rm), N/mm² | 470 – 630 (for 3 ≤ T ≤ 100mm) |
| Yield Strength (ReH Min), N/mm² | 355 (for T ≤ 16mm) |
| Min Elongation (%) | 22 (for T ≤ 40mm on gauge length 5.65 √S0) |
| Impact Properties | Minimum Average Energy (J) at -20°C: 27 |
| 1/8" IPS(.405" O.D.) | 3 1/2" IPS( 4.000" O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4" IPS(.540" O.D.) | 4" IPS(4.500" O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8" IPS(.675" O.D.) | 5" IPS( 5.563" O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2" IPS(.840" O.D.) | 6" IPS(6.625" O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4" IPS(1.050" O.D.) | 8 ” IPS(8.625" O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1" IPS:(1.315′ O.D.) | 10" IPS(10.750" O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4" IPS(1.660" O.D.) | 12" IPS(12.750" O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2" IPS(1.900" O.D.) | 14" IPS(14.000" O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2" IPS(2.375" O.D.) | 16" IPS(16.000" O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2" IPS(2.875" O.D.) | 18" IPS (18.000" O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3" IPS( 3.500" O.D.) | SCH 5, 10, 40, 80, 160, XXH |
| Hot Forming | Heat Treatment | |||
|---|---|---|---|---|
| Temperature°C | Cooling Type | Normalizing 1″ | Stress relieving anneal 2″ | Cooling Type |
| 700-750 | Air | 850-950°C | 580-630°C | Air |
| Outer diameter and wall Thickness | |||
|---|---|---|---|
| Execution | Size Range | OD Tolerance | Wall tolerance |
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall - 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall - 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 - 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 - 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
