At Amardeep Steel Centre, we provide Nimonic alloy 263, which is a nickel-cobalt-chrome-molybdenum alloy known for its age-hardening capabilities. This alloy was specifically designed to exhibit excellent fabrication characteristics in the annealed condition while maintaining strong strength properties after aging. Compared to materials like Waspaloy or Rene 41, Nimonic 263 is easier to form and weld, and it demonstrates exceptional ductility at intermediate temperatures.
Our Nimonic 263 is supplied in the annealed condition, offering excellent ductility that makes it suitable for both cold forming and hot working processes. When it comes to welding Nimonic 263, we recommend using filler wire with a matching composition in both TIG and MIG forms to ensure optimal results.
To achieve the desired properties and performance of Nimonic 263, we suggest the following heat treatments:
Extruded Bar:
- Solution Treatment: Heat the material to 1150 °C for 1.5-2.5 hours, followed by water quenching.
- Ageing Treatment: Heat the material to 800 °C for 8 hours, then allow it to cool in ambient air.
- (These treatments comply with BS HR10 and AMS 5886 standards.)
Hot-rolled Sheet:
- Solution Treatment: Heat the material to 1150 °C for 0.5 hours, followed by water quenching or air cooling.
- Ageing Treatment: Heat the material to 800 °C for 8 hours, then allow it to cool in ambient air.
- (These treatments comply with BS HR206 and AMS 5872 standards.)
Cold-rolled Sheet:
- Solution Treatment: Heat the material to 1150 °C for 3-10 minutes, followed by water quenching or fluidized bed quenching.
- Ageing Treatment: Heat the material to 800 °C for 8 hours, then allow it to cool in ambient air.
- (These treatments comply with BS HR206 and AMS 5872 standards.) By following these recommended heat treatments, you can ensure that Nimonic 263 exhibits the desired properties and delivers optimal performance. At Amardeep Steel Centre, we are dedicated to providing high-quality materials and assisting you in meeting your specific requirements
Chemical Composition
| Chemical Composition Limits | |||||||||
| Weight% | Ni | Cr | Mn | Si | C | Al | Ag | B | Fe |
| 263 | Bal | 19-21 | 0.60 max | 0.40 max | 0.04-0.08 | 0.60 max | 0.0005 max | 0.005 max | 0.07 max |
| Weight% | Cu | Mo | Co | Ti | Al+Ti | Pb | Bi | S | |
| 263 | 0.20 max | 5.6-6.1 | 19-21 | 1.90-2.40 | 2.40-2.8 | 0.0020 max | 0.0001 max | 0.007 max | |
Typical Mechanical Properties
| Material | Temp °C | Yield Strength 0.2% (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HB |
| Nimonic 263 Bar Solution Treated (AMS 5886/ BS HR10) |
RT | - | - | - | 248 max |
| Nimonic 263 Bar Heat Treated (AMS 5886 / BS HR10) |
RT | 585 (typical) | 1004 (typical) | 45 | - |
| Nimonic 263 Bar Heat Treated (AMS 5886/ BS HR10) |
780 | 403 (min) | 541 (min) | 12 | - |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % |
Hardness HRC |
| Nimonic 263 Sheet Solution Treated (AMS 5872 / BS HR206) |
RT | - | - | - | 22.5 max |
| Nimonic 263 Sheet Heat Treated (AMS 5872 / BS HR206 |
RT | 580 (typical) | 973 (typical) | 39 - | |
| Nimonic 263 Sheet Heat Treated (AMS 5872 / BS HR206 |
780 | 403 (min) | 541 (min) | 9 | - |
Specifications
• UNS N07263
• Werkstoff Nr. 2.4650
• BS HR10 Rod and Bar
• BS HR 206 Plate, Sheet, Strip
• BS HR 404 Seamless Tube
• AECMA PrEn 2199 Bar
• AECMA PrEn 2200 Forgings
• AECMA PrEn 2201 Bar
• AECMA PrEn 2202 Tube
• AECMA PrEn 2203 Sheet, Strip
• AECMA PrEn 2418 Plate
• DIN 17750 Plate, Sheet, Strip
• DIN 17752 Bar and Rod
• DIN 17753 Wire
• DIN 17754 Forgings
• AMS 5872 Sheet, Plate and Strip
• AMS 5886 Bar, Forgings, Rings
• AFNOR NCK 20 D
• AIR 9165 Sheet, Plate, Rod, Bar and Forgings
• MSRR 7035
• MSRR 7036
• GE B50A774A
• Tradename's: Nicrofer 5120, Hastelloy C263 and Nimonic 263.
