These ASTM A519 GR. 1026 Boiler Piping is being manufactured by utilizing regular quality natural materials and improves the efficient life of these products in addition to their performance. In the interim, the part of ASME SA 519 GR. 1026 Boiler Tubes is hounded by the thickness and length of different sides. We are the most trusted name among the top Suppliers & Manufacturers, Exporting ASTM A519 GR. 1026 Boiler Tubes from India.
In contrast with grade 1020, the ASTM A519 1026 Steel Chromoly Tubing is typically those cylinders where the OD is bigger than 2 inches and divider thicknesses for these A519 gr 1026 Seamless Steel Tubing is by and large heavier than 156".
The ASTM A519 Grade 1026 cylinder is normally produced by hot working steel. The hot worked steel made under this determination could either be carbon steel or this interaction could be utilized to make the ASTM A519 1026 Chrome Alloy Steel HF SMLS Tubing. In the event that essential, the Chrome Moly Steel ASTM A519 1026 Boiler Tubing could be thusly cold wrapped up by hot working the cylindrical item. Hot working the Alloy Steel ASTM A519 1026 Square Tubing to create the ideal measurements, shape just as specific properties.
The predetermined ASTM A519 Grade 1026 tubes are by and large outfitted in the accompanying shapes for example rectangular, round or square. Whenever needed, At Amardeep Steel Centre, we Manufacture & Supply these ASTM A519 Grade 1026 Mechanical Tubing outfitted in exceptional areas, as indicated by the need of our customers or on the other hand whenever needed by the application for which it is to be utilized for. Hotness examination is typically performed on the ASTM A519 Grade 1026 Steel Tubing to decide the rates of the components determined in the material used to make these cylinders. Albeit auxiliary dissolving measures are utilized in the softening of A519 gr 1026 Seamless Tubing, the hotness examination could be gotten either from one re-liquefied ingot or the result of one re-dissolved ingot of each and every essential liquefy. The ASTM A519 1026 Hot Finished Tubing must be covered with a film of oil prior to molding to impede rust when indicated.
Specification for ASTM A519 Grade 1026 Pipes & Tubes: |
||
| Standard | : | ASTM A519 / ASME SA 519 |
| ASTM A519 | : | Standard Specification covers both seamless hot-finished mechanical tubing and seamless cold-finished mechanical tubing |
| Size | : | 12 3/4(323.8mm) |
| Outer Diameter | : | 6.25-1800mm |
| Schedule | : | 10 – XXS / Thk |
| Shape | : | round, square,rectangular and special sections. |
| Length | : | Single random length/Double random length or as customer’s actual request |
| Grade | : | 1026 |
GR.1026 A519 Seamless Pipes & Tubes Chemical Composition :
| Grade | C | Mn | P≤ | S≤ |
| 1026 | 0.22-0.28 | 0.60-0.90 | 0.040 | 0.050 |
ASME SA519 GR.1026 Standard Pipes Mechanical Properties :
| Properties | Metric | Imperial |
| Tensile strength | 490 MPa | 71100 psi |
| Yield strength | 415 MPa | 60200 psi |
| Bulk modulus (typical for steel) | 140 GPa | 20300 ksi |
| Shear modulus (typical for steel) | 80.0 GPa | 11600 ksi |
| Elastic modulus | 190-210 GPa | 27557-30458 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break (In 50 mm) | 15.00% | 15.00% |
| Reduction of area | 40.00% | 40.00% |
| Hardness, Brinell | 143 | 143 |
| Hardness, Knoop (converted from Brinell hardness) | 163 | 163 |
| Hardness, Rockwell B (converted from Brinell hardness) | 78 | 78 |
| Hardness, Vickers (converted from Brinell hardness) | 149 | 149 |
| Machinability (based on AISI 1212 steel as 100 machinability. The machinability of Group I bar, rod, and wire products can be improved by cold drawing.) | 75 | 75 |
Outside Diameter Tolerances for round Hot-Finished Tubing: :
| Outside Diameter Tolerances for Round Hot-Finished Tubing A, B, C | ||
| Outside Diameter Size Range, In.(mm) | Outside Diameter Tolerance, in. (mm) | |
| Over (+) | Under (-) | |
| up to 2.999 (76.17) | 0.020 (0.51) | 0.020 (0.51) |
| 3.000-4.499 (76.20-114.27) | 0.025 (0.64) | 0.025 (0.64) |
| 4.500–5.999 (114.30–152.37) | 0.031 (0.79) | 0.031 (0.79) |
| 6.000–7.499 (152.40–190.47) | 0.037 (0.94) | 0.037 (0.94) |
| 7.500–8.999 (190.50–228.57) | 0.045 (1.14) | 0.045 (1.14) |
| 9.000–10.750 (228.60–273.05) | 0.050 (1.27) | 0.050 (1.27) |
| A. Diameter tolerance is not applicable to normalized and tempered or quenched and tempered conditions. |
| B. The common range of sizes of hot finished tubes is 11⁄2 in. (38.1 mm) to 103⁄4 in. (273.0 mm) outside diameter with wall thickness at least 3 % or more of outside diameter, but not less than 0.095 in. (2.41 mm). |
| C. Larger sizes are available, consult the manufacturer for sizes and tolerances. |
Dimensions of A519 Grade 1026 Seamless Tubes:
| Outer Diameter | Wall Thickness | Length | |
| Cold Drawn | 3/4 to 15 Inch | 1/8 to 1 1/2 Inch | 12000 mm max |
| Hot Rolled | 2 to 30 Inch | 1/8 to 8 Inch | 12000 mm max |
Chromoly ASTM A519 Grade 1026 Cold Worked Tubing Dimension Tolerances :
| Pipe Type | Pipe Sizes | Tolerances | |
| Cold Drawn | OD | ≤48.3mm | ±0.40mm |
| WT | ≥60.3mm | ±1%mm |
ASTM A519 1026 Grade Annealed Tubing wall thickness Tolerances (A. B, C Round):
| Cold Drawn Maximum % Over and Under Nominal | Wall Thickness % of OD | |
| ID Up To 1.499 Inches | ID 1.500 Inches and Over | |
| 10 | 7.5 | 25 and Under |
| 12.5 | 10 | Over 2 |
Sizing Method
- HF-Hot Finished,
- CW-Cold worked,
- RT-Rough Turned,
- G– Ground.
Thermal Treatments:
- A-Annealed,
- N– Normalized,
- QT-Quenched and Tempered,
- SR-Stress Relieved or Finish Anneal.
